Zhanruisc8541EMultimedia network camera playback-LCD driver integrated board
Zhanruisc8541EMultimedia network camera playback-LCD driver integrated board
1 Product Overview
YL21It is a product based onunisoc mainchip8541EMultimedia network camera playback for-LCD driver integrated board。This motherboard can support bothSPI/MIPIMultiple dual screen display modes such as dot screen selection。Driveable7-10Inch LCD display screen，Maximum supportedFHDofTFTLCD screen，It is a professional and highly integrated productAndroidIntelligent solutions,Simultaneously supported4GAll network connected，The system is integratedGPS Beidou WIFIBluetooth，Support for dual camera，support1080PCamera and video recording，Supports various sound playback formats，Rich peripheral interfaces and extensive power supply，It is a highly integrated and cost-effective Android4GSmart board，With rich peripheral functions，Covering a vast range of industry application scenarios。
2 Product specifications
2.1Basic hardware specifications：
|
CPU |
unisoc 8541E，QuadrupoleARM Cortex A53 1.8 GHz |
|
GPU |
Binuclear nucleusARM Mali-T820 MP |
|
Memory |
1GB or 2GB |
|
Built in storage capacity |
8GB |
|
Point screen interface |
1 channelSPIinterface（Single channel 6 or 8 bit）。Supports a maximum resolution of 240x320，2.4" display screen 1 channelMIPIinterface（Single 8-bit）。Supports maximum resolution of 1920x1080，4"-10" display screen |
|
LCDVoltage Options |
LCD_VCCVoltage support 3.3V/5VOptional LCD_Backlight voltage support 5VOptional |
|
network interface |
have2G 3Gand 4G All network communication Support for telecommunications move Unicom。 |
|
Equipped with Bluetooth+WifiIntegrated module，supportWi-Fi 802.11b/g/nprotocol,2.4G Supports Bluetooth4.0 Protocol, |
|
|
Equipped with built-inGPS/Beidou Supports high-precision positioning |
|
|
supportUVC camera |
|
|
4-wayUSB HOST，One of them supportsUSB OTG supportUSB2.0 high speed 480bps |
|
|
4-wayUARTSerial port(One of them isRS232） 1 channelRS485interface（defaultRS485） 1 channelSPIinterface |
|
|
1-way backlight connection |
|
|
2-way button interface，1-way reservedGPIO，1 channelMICinput |
|
|
D classLarge built-in dual speaker，5W*2 4 Ohms |
|
|
System watchdog |
Support hardware+Software dual watchdog function |
|
touch screen |
1 channelI2C，multichannelUSBinterface：Supports infrared、resistance、Capacitive touch screen |
|
source |
input： DC12V |
