Allwinnertech A64 wireless multimedia decoding LCD driver video image decoding development board
Allwinnertech A64 wireless multimedia decoding LCD driver video image decoding development board
1 Application occasions
A64 boards are usedAllwinnertech A64programme，Integrated multimedia decoding、LCD driver、WIFI、Bluetooth、Ethernet、3G/4G（External extension）Integrated，Supports decoding of the vast majority of currently popular video and image formats,LVDSsingle/Dual 8-way interface，MIPIInterfaces, etc，Can drive variousTFT LCDdisplay screen，Greatly simplify the overall system design，sdcard，Stronger stability，Perfect for advertising machines、Cash register、Digital signage 、Intelligent terminal motherboard for vehicles and other related devices。
Chapter 2 Product Features
◆ integrationUSB/LVDS/MIPI/WIFI/BT/Integrated，Simplify overall machine design，PluggableTFcard.
◆ Rich extension interfaces.FiveUSBinterface(Three pins,1 standardUSBmouth，1MINIUSBinterface),Two expandable serial ports,GPIO/ADCinterface，Can meet the requirements of various peripherals in the market.
◆ high definition。Maximum support of 1080PDecoding and variousLVDS/EDPsignalLCDdisplay screen.
◆ Fully functional。Support horizontal and vertical screen playback，Video split screen，Scrolling subtitles，Timing switch，USBData import and other functions。
◆ Convenient management：Humanized playlist creation software，Easy to manage and control advertising playback。Play log，Easy to understand playback situation。
Chapter 3 technical parameter
|
Main hardware indicators |
|
|
CPU |
Allwinnertech A64 , Quadrupole，64 bit，Main frequency 1.2GHz |
|
Memory |
1/2G(Optional），Default 1GB |
|
Built-in memory |
EMMC 8/16/32G(Optional)，Default 8GB |
|
Decoding resolution |
Up to 1080 supportedP |
|
operating system |
Android 6.0 andAndroid 8.1 |
|
Playback mode |
Supports loops、timing、Multiple playback modes such as insert playback |
|
Network support |
holdWiFi/Bluetooth 4.0，Outward expansion（Ethernet、branch、3G/4G） |
|
Video playback |
supportwmv、avi、flv、rm、rmvb、mpeg 、ts、mpGrade 4 |
|
Image Format |
supportBMP、JPEG、PNG、GIF |
|
USB2.0 interface |
1USB HOST, 1MINIUSB ,3 scalableUSB |
|
Serial port |
2 serial port pins |
|
WIFI、BT |
built-inWIFI，BT4.0（Optional） |
|
SDcard |
supportSDcard |
|
LVDSoutput |
6/8-bit dual channelLVDS，Can directly drive 50/60HzLCD screen |
|
MIPI |
40P FPC 0.5mm MIPIinterface |
|
Audio and video output |
Supports stereo output,OnboardDClass 3W*2power amplifier |
|
RTCReal time clock |
support |
|
Timing on/off machine |
support |
|
System upgrade |
Support localSD,OTG USBupgrade |
