Home > TVS diodes >

Part Number	Power(W) All 3000 Filter Reset	Vrwm(V) All 11 12 13 14 15 16 17 18 20 22 24 26 28 30 33 36 40 43 45 48 51 54 58 60 64 70 75 78 85 90 100 110 120 130 150 Filter Reset	Vbr(V) All 12.2 13.3 14.4 15.6 16.7 17.8 18.9 20 22.2 24.4 26.7 28.9 31.1 33.5 36.7 40 44.4 47.8 50 53.3 56.7 60 64.4 66.7 71.1 77.8 83.3 86.7 94.4 100 111 122 133 144 167 Filter Reset	Vc(V) All 18.2 19.9 21.5 23.2 24.4 26 27.6 29.2 32.4 35.5 38.9 42.1 45.4 48.4 53.3 58.1 64.5 69.4 72.7 77.4 82.4 87.1 93.6 96.8 103 113 121 126 137 146 162 177 193 209 243 Filter Reset	Ipp(A) All 12.3 14.4 15.5 16.9 18.5 20.5 21.9 23.8 24.8 26.5 29.1 31 32.1 34.4 36.4 38.8 41.3 43.2 46.5 51.6 56.3 62 66.1 71.3 77.1 84.5 92.6 102.7 108.7 115.4 123 129.3 139.5 150.8 164.8 Filter Reset	Ir@25°C(μA) All 5 10 20 50 100 200 500 800 Filter Reset	Package All SMB Filter Reset
SMB30J11A SMB30J11CA	3000	11	12.2	18.2	164.8	800	SMB
SMB30J12A SMB30J12CA	3000	12	13.3	19.9	150.8	800	SMB
SMB30J13A SMB30J13CA	3000	13	14.4	21.5	139.5	500	SMB
SMB30J14A SMB30J14CA	3000	14	15.6	23.2	129.3	200	SMB
SMB30J15A SMB30J15CA	3000	15	16.7	24.4	123	200	SMB
SMB30J16A SMB30J16CA	3000	16	17.8	26	115.4	100	SMB
SMB30J17A SMB30J17CA	3000	17	18.9	27.6	108.7	50	SMB
SMB30J18A SMB30J18CA	3000	18	20	29.2	102.7	20	SMB
SMB30J20A SMB30J20CA	3000	20	22.2	32.4	92.6	10	SMB
SMB30J22A SMB30J22CA	3000	22	24.4	35.5	84.5	5	SMB
SMB30J24A SMB30J24CA	3000	24	26.7	38.9	77.1	5	SMB
SMB30J26A SMB30J26CA	3000	26	28.9	42.1	71.3	5	SMB
SMB30J28A SMB30J28CA	3000	28	31.1	45.4	66.1	5	SMB
SMB30J30A SMB30J30CA	3000	30	33.5	48.4	62	5	SMB
SMB30J33A SMB30J33CA	3000	33	36.7	53.3	56.3	5	SMB
SMB30J36A SMB30J36CA	3000	36	40	58.1	51.6	5	SMB
SMB30J40A SMB30J40CA	3000	40	44.4	64.5	46.5	5	SMB
SMB30J43A SMB30J43CA	3000	43	47.8	69.4	43.2	5	SMB
SMB30J45A SMB30J45CA	3000	45	50	72.7	41.3	5	SMB
SMB30J48A SMB30J48CA	3000	48	53.3	77.4	38.8	5	SMB
SMB30J51A SMB30J51CA	3000	51	56.7	82.4	36.4	5	SMB
SMB30J54A SMB30J54CA	3000	54	60	87.1	34.4	5	SMB
SMB30J58A SMB30J58CA	3000	58	64.4	93.6	32.1	5	SMB
SMB30J60A SMB30J60CA	3000	60	66.7	96.8	31	5	SMB
SMB30J64A SMB30J64CA	3000	64	71.1	103	29.1	5	SMB
SMB30J70A SMB30J70CA	3000	70	77.8	113	26.5	5	SMB
SMB30J75A SMB30J75CA	3000	75	83.3	121	24.8	5	SMB
SMB30J78A SMB30J78CA	3000	78	86.7	126	23.8	5	SMB
SMB30J85A SMB30J85CA	3000	85	94.4	137	21.9	5	SMB
SMB30J90A SMB30J90CA	3000	90	100	146	20.5	5	SMB

12 page: Go
