signal protection
31.1 CVBS Interface Surge Protection Scheme
Advantages of the scheme: it is used for lightning surge protection of CVBS interface .
Integrity.
Meet IEC61000-4-5 , GB/T17626.5 8/20μs 400A , 10/1000μs 100A .
