2.6 Split lightning protection scheme for 100Mbps network
Advantages: Used for the 100M network port lightning protection outdoors. This solution adopts a two-stage protection with reliable operation, ensuring the integrity of signals under high temperatures, meeting IEC61000-4-2, Level 4, contact discharge 30kV, air discharge 30kV. IEC61000-4-5 10/700μs, 40Ω, 6kV, ±5 times, the 100M network port can be expanded to 4 ports.
